Product Details:

Place of Origin: Henan, China
Brand Name: FRP safety grating
Model Number: frp safety grating

Payment & Shipping Terms:

Minimum Order Quantity: 1000 kilograms
Price: $2.50/kilograms >=1000 kilograms
Get Best Price Contact Now

Detail Information
Application: FRP Walkway Surface Treatment: Anti-slip
Technique: Pultruded Processing Service: Cutting
Material: FRP Open Area: 40% 80%

Product Description

Products Description
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 0
Fiberglass Reinforced Phenolic Grating (FRP Grating) is a composite material made of fiberglass reinforcements embedded in a phenolic resin matrix.

1- manufactured by assembly of pultruded I-Beam & pultruded cross rods. The distance between I-Beam & cross rods depend upon various load conditions.

2. 25mm,38mm, 40mm, 50mm,58mm,65mm high grating are available;

3-Can be cut at any lengths you need; open area is decided by customer

4.Fiberglass grating can enhance surface slip resistance by adding a layer of sand
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 1
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 2
Grating clamps are available.
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 3
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 4
Pultruded FRP grating specification list
the open area of pultruded FRP grating dimensions could be adjusted as requirement, below is popular size list
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 5
Art No.
“I”high A
(mm)
“I"Top width B
(mm)
"I" bottom width D (mm)
clearance C
(mm)
open area
approx weight
(kg/sqm）
5025
25
30
30
30
50
10
4025
25
15
15
10
40
13.8
5025
25
15
15
15
50
11.9
6025
25
15
15
23
60
10
4038
38
15
15
10
40
20.5
5038
38
15
15
15
50
17.8
6038
38
15
15
23
60
14.8
6038ii
38
15
15
23
60
19.2
4040
40
40
20
27
40
19.5
5040
40
40
20
40
50
17
6040
40
40
20
60
60
14
4040i
40
30
30
20
40
14
5040i
40
30
30
30
50
12
6040i
40
30
30
45
60
10
6050
50
15
15
23
60
16
5050
50
15
15
15
50
22.5
4050
50
15
15
10
40
25.5
4058
58
15
15
10
40
32
5058
58
15
15
15
50
27
6058
58
15
15
23
60
22
4065
65
30
30
20
40
17
5065
65
30
30
30
50
15
6060
60
30
30
45
60
12
phenolic grating is commonly used on ships and offshore drilling platforms among other marine structures.
Due to the highlycorrosive and humid nature of marine environments, traditional metal materials are susceptible to corrosion and rust,necessitating corrosion-resistant alternatives to meet specific requirements.
Phenolic grating offers excellent corrosion resistance, weather resistance, and durability, capable of withstanding the harsh conditions of seawater, salt spray, UV radiation, etc.
Therefore, it is widely applied in locations such as vessels, offshore platforms, docks, and marine structures, serving as construction materials for flooring, platforms, walkways, and safety railings, among other facilities.
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 6
offshore platform walkway
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 7
Ship decking
Related Product
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 8
FRP Handrail/Fence/Guardrail
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 9
FRP Stair Step Ladder With Handrail
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 10
FRP Step Ladders
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 11
FRP Support Beam For Grating Floor
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 12
FRP Structural Profiles
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 13
FRP Molded Grating
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 14
Antislip FRP Decking Strip
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 15
FRP Handrail Fittings
FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass 16
FRP Cable Tray
Packing And Shipping
Packing type: pallets, wood carton, etc. also could packing according to customer's requirement.
Shipping： land shipping, air shipping, railway shipping, express delivery(length can't over 2.5m)
